mowing width/height (mm)

Mowing width 550mm, mowing height 0-200mm

configuration

motor

Runtong, Loncin, Yamaha (196cc/224cc);

power system

Built-in generator 2200W，12.5A Chaowei x2 24V

Powertrain

Drive power 800W*2 integrated gearbox, hybrid (manual throttle), 9.5 horsepower, manual/electric start, 32 engineering rubber tracks;

Remote control system

500m remote control distance/high and low speed;

fuel system

Gasoline capacity 1.4L, fuel consumption 2L, engine oil capacity 0.6L;

Working driving system

Climbing height 50°, travel speed 0-4km/h, working efficiency ≤2200m²/h;

Overall dimensions/weight

Bare machine dimensions: 940*940*550mm, bare machine weight: 140kg; Package dimensions: 1020*1000*790mm, package weight: 170kg;
